Carbon Nano Particles

SiNON Nano Sciences leverages the advanced features of Carbon Nano Particles to pioneer innovative solutions in the field of therapeutics. By integrating the unique properties of Raman Spectra, FTIR imaging, DLS size distribution, solubility, and fluorescence capability, we ensure the development of cutting-edge therapeutic and diagnostic applications that are both effective and reliable. Our commitment to harnessing the potential of CNPs underscores our dedication to advancing healthcare and improving patient outcomes

Multiple Applications

A platform technology with diverse applications

CNP Therapeutics in SiNON

CNP Therapeutics

Targeted Drug Delivery Controlled-release Cross the Blood Brain Barrier

Fluorescent Bio Sensing and Imaging in SiNON

Fluorescent Bio-Imaging & Sensing

Non-invasively Self-fluorescing Diagnostic
tools In Vitro Bio Sensing

Oncology applications in SiNON

Oncology Applications

Oncology-Combination Therapy Diabetes (oral insulin) Regenerative Medicines Cardiology.

pH Based Configuration in SiNON
pH-Based Configuration of Carbon Nanoparticles for Targeted Delivery

pH-based configuration of Carbon Nanoparticles (CNPs) is a cutting-edge approach in targeted drug delivery that utilizes the acidic environment of specific tissues, such as tumors, to ensure precise and controlled release of therapeutic agents.

Targeted Release: CNPs are engineered to release drugs in response to the acidic pH of diseased tissues, ensuring localized and controlled delivery.

Enhanced Efficacy
:
This approach increases the therapeutic impact by concentrating the drug in the affected area, reducing systemic exposure.

  • ATR(IR) of CNP Arginine in SiNON

    The image shows an infrared (IR) spectrum obtained via Attenuated Total Reflectance (ATR) spectroscopy, displaying two distinct plots in red and blue, representing different samples or conditions of CNP (possibly...

  • CNP of ATR-IR in SiNON

    The image represents an ATR-IR (Attenuated Total Reflectance Infrared Spectroscopy) spectrum of Carbon Nanoparticles (CNP).

  • The image shows an infrared (IR) spectrum obtained via Attenuated Total Reflectance (ATR) spectroscopy, displaying two distinct plots in red and blue, representing different samples or conditions of CNP (possibly...

  • DLS of CNP in SiNON

    The image shows an infrared (IR) spectrum obtained via Attenuated Total Reflectance (ATR) spectroscopy, displaying two distinct plots in red and blue, representing different samples or conditions of CNP (possibly...

Solvent Solubility
H2O
Soluble
EtoH
Soluble
ACN
Partially Soluble
DMF
Soluble
DCM
Insoluble
Toluene
Insoluble
DMSO
Soluble
IPA
Partially Soluble
Solubility of Carbon Nanoparticles (CNPs) in Various Solvents

In a study, 0.01 grams of Carbon Nanoparticles (CNPs) were dispersed in 10 mL of various solvents and sonicated for 10 minutes.

Soluble in:
H₂O:
Complete solubility, ideal for biological applications like drug delivery and bioimaging.
Ethanol (EtOH): Soluble, indicating potential for alcohol-based systems.
Dimethylformamide(DMF): High polarity makes DMF suitable for organic synthesis and polymer chemistry.
Dimethylsulfoxide(DMSO): Soluble in both polar and nonpolar environments.

Partially Soluble in:
Acetonitrile (ACN): Partial solubility, may not suit applications needing full dispersion.
Isopropanol (IPA): Some solubility, useful in specific formulations.

  • Zeta Arginine of SiNON

    The Zeta potential of -33 mV for carbon nanoparticles functionalized with Arginine highlights their stability and surface charge in suspension. The negative charge ensures electrostatic repulsion between particles, preventing aggregation...

  • Zeta CNP in SiNON

    Zeta potential is a key measure of nanoparticle stability and surface charge in suspension, expressed in millivolts (mV). A value of -41.09 mV indicates a highly negative charge, promoting strong...

  • FESEM 500 nm in SiNON

    A FESEM (Field Emission Scanning Electron Microscope) image of CNPs (Carbon Nanoparticles) provides a highly detailed view of the structure, morphology, and surface characteristics of these particles at the nanoscale.

Element App Conc. Intensity Corrn. Weight% Weight % Sigma Atomic%
C
0.23
0.9014
21.38%
2.12%
26.59%
O
1.08
1.1381
78.62%
2.12%
73.41%
Totals
100.00
  • Electron Images in SiNON

    EDX

    EDX (Energy Dispersive X-ray Spectroscopy) is a powerful analytical technique often used in conjunction with Scanning Electron Microscopy (SEM), including Field Emission Scanning Electron Microscopy (FESEM), to characterize the elemental composition of materials such as  (CNPs).
